车型简介：
国产6x6全驱越野自卸车出口价格六驱越野自卸车价格

订购热线：188 0728 8787

产品介绍

Driving type驱动方式		6×6
Vehicle kerb mass (kg)整车整备质量		15800
Max. gradeability(%) 最大爬坡度		30
Overall dimensions (mm) 外型尺寸 Length长×Width 宽×Height高		920024903500
Wheel base (mm)轴距		4375+1400
Engine发动机		WP10.380
Horse power 马力		380
Displacement(L)排量		9.769
Fuel tank capacity (L)油箱		400L aluminium tank
Tyre轮胎		12.00R20
Gearbox变速箱	Transmission变速箱	12JSD200T-B power take-off, 12 forward speeds, 2 reverse speeds. 12个前进挡，2个后退挡
	Max. torque (N.m)最大扭矩	2000
Front axle前轴		MAN 9T front axle 9吨
Drive axle 驱动桥		MAN 16T×2 double reduction driving axle 16吨
Frame type and specification 车架型式及规格		850×300（8+7），直纵梁 straight beam.
Suspension 悬架		Front and rear multiple leaf-springs, four main springs+ four U-type bolts 前后多片簧,四主片+四骑马螺栓
Cab驾驶室		D’LONG F3000 lengthened flat cab, Air suspension driver’s seat, 4-point hydraulic suspension cab, one sleeping bed, A/C, Electric window machine, Electric flip ,metal bumper、Front headlight and rear taillight protection grid, water tank protection grid, oil-bath air filter F3000加长平顶驾驶室、空气主座椅、四点液压悬浮驾驶室、单卧铺、电控自动恒温空调、电动摇窗机、手动翻转、金属保险杠
Platform dimentions(mm) 货箱规格		长度6.0米、宽度2.35米，高1.5米，板材厚度：边8底10
